DPR 100 is a battery powered pressure recorder, with LCD display. It is perfect for applications requiring display pressure readings. Available on-screen data includes: statistics (max., min., average); recording status (start, stop and recording rate), display options (channel, units, text size); calibration information (data calibrated, data for recalibration). Statistics can be cleared at any time during logging. With 250000 readings, the DGR100 has one of the largest memory capacities .The non-volatile memory will retain recorded data, even if battery power is lost. Simply connect the interface cable to an availableUSBPortwith a few clicks of the mouse, data is downloaded and ready for review and export to EXCEL.
Application:
Features:
Technical Specifications:
Other Specification:
Environmental:
Conventional Pressure Range Selection
No. |
Pressure Range |
Accuracy |
Accuracy |
Accuracy |
DPR100-1 |
(-1~0)bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-2 |
(0~0.16) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-3 |
(0~0.25) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-4 |
(0~0.4)bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-5 |
(0~0.6) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-6 |
(0~1)bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-7 |
(0~1.6)bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-8 |
(0~2.5) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-9 |
(0~4) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-10 |
(0~6) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-11 |
(0~10) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-12 |
(0~16) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-13 |
(0~25) bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-14 |
(0~40)bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-15 |
(0~60)bar |
0.05, G |
0.1,G |
0.2,G |
DPR100-16 |
(0~100)bar |
0.05, G |
0.1,SG |
0.2,SG |
DPR100-17 |
(0~160 )bar |
0.05, G |
0.1,SG |
0.2,SG |
DPR100-18 |
(0~250)bar |
0.05, G |
0.1,SG |
0.2,SG |
DPR100-19 |
(0~400) bar |
0.05, G |
0.1,SG |
0.2,SG |
DPR100-20 |
(0~600) bar |
0.05, G |
0.1,SG |
0.2,SG |
DPR100-21 |
(0~700) bar |
0.05, G |
0.1,SG |
0.2,SG |
Remark: Other pressure ranges are available. Contact Factory with specific requirement.
G=Gauge Pressure; SG=Sealed Gauge Pressure;
Bottom Connect thread : 1/4NPT.1/2NPT.G1/2 ( Or custom-made)
